Specification Of Ducati Monster 696:
- Model: Ducati Monster 696
- Year: 2010
- Category: Naked bike
- Engine and transmission
- Displacement: 696.00 ccm (42.47 cubic inches)
- Engine type: V2
- Stroke: 4
- Power: 78.85 HP (57.6 kW)) @ 9000 RPM
- Torque: 50.60 Nm (5.2 kgf-m or 37.3 ft.lbs)
- Compression: 10.7:1
- Bore x stroke: 88.0 x 57.2 mm (3.5 x 2.3 inches)
- Fuel system: Injection. Siemens electronic fuel injection, 45mm throttle body
- Valves per cylinder: 2
- Fuel control: Desmodromic valve control
- Starter: Electric
- Cooling system: Air
- Gearbox: 6-speed
- Transmission type
- final drive: Chain
- Clutch: APTC wet multiplate with hydraulic control
- Physical measures
- Dry weight: 161.0 kg (354.9 pounds)
- Seat height: 770 mm (30.3 inches) If adjustable, lowest setting.
- Wheelbase: 1,450 mm (57.1 inches)
- Chassis and dimensions
- Frame type: Tubular steel Trellis frame
- Rake (fork angle): 24.0°
- Front suspension: Showa 43mm upside-down forks
- Rear suspension: Progressive linkage with preload and rebound Sachs adjustable monoshock
- Front tyre dimensions: 120/60-ZR17
- Rear tyre dimensions: 160/60-ZR17
- Front brakes: Double disc
- Front brakes diameter: 320 mm (12.6 inches)
- Rear brakes: Single disc
- Rear brakes diameter: 245 mm (9.6 inches)
- Exhaust system: 2 aluminum mufflers
- Speed and acceleration
- Power/weight ratio: 0.4898 HP/kg
- Other specifications
- Fuel capacity: 15.00 litres (3.96 gallons)
- Color options: White, black, red
